Last Updated on June 5, 2026
If you are the type who likes to clearly know what is going on with your computer in regard to traffic from the network or from the internet, you definitely want to consider installing some dedicated network monitoring software on your PC. The massive problem with standard network monitoring software is that it tends to be ridiculously complex. If you are not a seasoned network administrator, it might give you way more raw data than you need or will actually understand.
Fortunately, there is a completely free monitoring application that accurately gives you the exact information you need without confusing you at the exact same time. We will be showing you exactly how to safely monitor your network and internet traffic with Sniffnet. This lightweight utility provides a beautiful visual interface to track every single byte of data leaving your machine.
Installing Sniffnet and Npcap
1. Download the Required Software
Sniffnet is a completely free network and internet monitoring app that you can quickly download directly from their official website here. At the very end of the core installation process, the setup wizard will explicitly prompt you to download Npcap directly onto your computer. This secondary background application is absolutely needed for Sniffnet to capture local data and work properly.
2. Install the Packet Sniffer Driver
Npcap is a highly specialized packet capture and network monitoring software explicitly built for Windows. It acts as a vastly improved modern version of the legacy WinPcap utility. This required background driver offers much better tracking performance, tighter security, and deep native support for modern Windows operating systems.
Configuring the Sniffnet Interface
1. Select Your Active Network Adapter
Once you successfully have Npcap installed, you can actively start the Sniffnet program on your desktop. You must deliberately choose the specific physical network adapter you want to use for the live monitoring process. This crucial step forces the software to listen to the exact hardware routing your active internet connection.
2. Filter the Network Protocols
You can dynamically decide if you want to aggressively monitor IPv4, IPv6traffic, or both completely simultaneously. You can also explicitly monitor specific TCP, UDP, and ICMP traffic packets passing through your router. Simply uncheck any specific protocol option you do not strictly wish to see cluttering up the application interface. Once you securely make your visual selections, click on the prominent rocket icon to officially start the live monitoring process.
Reading Your Network Traffic Data
1. Analyze the Visual Traffic Rate
You will instantly see the raw network traffic beautifully represented by a live scrolling graph located in the Traffic rate section. Incoming download traffic will be brightly represented in solid orange across the screen. Outgoing upload traffic will be explicitly shown in contrasting blue to make tracking background uploads incredibly easy.
2. Identify the Target Network Hosts
The Network host section will precisely show you other local computers sitting on your private network. It also reveals the exact IP addresses and remote websites that are actively sending background traffic directly to your computer. It utilizes the exact same orange and blue color coding schema to perfectly differentiate between incoming and outgoing data streams. You can quickly change the default data representation from bytes to packets if you would rather see that specific type of technical layout.
3. Track a Large File Download
We will now physically start to download a massive 5GB ISO file directly from the Ubuntu Linux website to force a traffic spike. Now we can clearly see the live traffic rate absolutely increase quite a bit right on the visual graph. The massive data spike is prominently shown in bright orange since it strictly represents heavy incoming download traffic.
4. Pinpoint the Exact Data Source
We can also clearly verify that the massive file download is specifically coming directly from the pdx.edu datacenter server. The software explicitly shows the exact amount of raw data that has been successfully downloaded so far sitting right at 1.8GB. This lets you accurately pinpoint exactly which specific background connection is hogging your limited bandwidth.
Setting Up Custom Sniffnet Alerts
1. Configure Host Notification Settings
Sniffnet can be heavily configured with custom favorites by navigating straight into the application notifications settings menu. You must check the specific box right next to the label stating Notify me when new data are exchanged from my favorites. The application will also audibly play a custom sound file when your flagged favorites are actively sending or receiving network traffic. You can easily enable this audio alert feature by clicking on the small gear settings button located at the upper right corner of the app.
2. Add a Host to Your Favorites
To permanently add a specific remote host as a tracked favorite, simply click the empty star icon sitting right next to it in the hosts section. The star will instantly turn solid yellow to indicate it is being actively monitored by the alert system. Then whenever background traffic is exchanged directly from that specific host, you will distinctly hear the specific notification sound associated with it.
3. Review the Triggered Notifications
Now when you navigate back over to the dedicated notifications tab, you will see a highly detailed timestamped log. The software explicitly shows that specific data has been actively exchanged directly from your tracked network favorite. This is incredibly useful for tracking silent background updates or hidden telemetry connections happening without your permission.
Using the Deep Inspection Tools
1. Explore the Advanced Inspect Tab
The dedicated Inspect tab is strictly used to show highly specific technical information about the active network traffic. This powerful grid reveals exact source addresses, local network ports, destination routing, raw protocols, active services, total bytes, and raw packets. You can easily sort these data columns to instantly find the heaviest hidden background connections draining your resources.
2. Apply Custom Traffic Filters
You can aggressively filter on all of these technical fields directly from the top interface control bar. You can also quickly filter the massive list by your saved favorites, specific domain names, connection counts, and the active autonomous system name. If you explicitly enable the Only show favorites filter, you can clearly see that all the other noisy background hosts will absolutely not show up in the cluttered list. You can also distinctly see both receiving and sending network traffic perfectly isolated on the screen.
3. Try Alternative Monitoring Apps
As you can see, Sniffnet is fairly basic yet actively provides extremely useful visual information to help you effectively monitor your raw network and internet traffic. If you are specifically looking for a totally different basic tool that can monitor physical devices on your network to verify they are currently online, you have other options. You can easily check out the completely free Network Alarmer app to perform basic uptime pings instead of deep packet inspection.
